Mounting system/

CANTILEVER ARMS

KONZOLY
KONZOLY
KONZOLY
  • Technical data
  • material: steel
  • galvanized
Ordering code
CAD
L (mm)
Packaging in pcs
Typ
Thickness of the material (mm)
For system
Size of the base (mm)
Number of packaging
Demand
Ordering code CAD L (mm) Packaging in pcs Typ Thickness of the material (mm) For system Size of the base (mm) Number of packaging Demand
332271820 200 20 Cantilever arms 27/18 1,25 light 120×40×4
332271830 300 20 Cantilever arms 27/18 1,25 light 120×40×4
332271850 500 10 Cantilever arms 27/18 1,25 light 120×40×4
332271860 600 1 Cantilever arms 27/18 1,25 light 120×40×4
332283020 200 10 Cantilever arms 28/30 1,75 light 120×40×4
332283030 300 10 Cantilever arms 28/30 1,75 light 120×40×4
332283044 440 10 Cantilever arms 28/30 1,75 light 120×40×4
332283050 500 10 Cantilever arms 28/30 1,75 light 120×40×4
332283060 600 1 Cantilever arms 28/30 1,75 light 120×40×4
332283075 750 1 Cantilever arms 28/30 1,75 light 120×40×4
332283090 900 1 Cantilever arms 28/30 1,75 light 120×40×4
332384420 200 10 Cantilever arms 38/40 2 light 120×40×6
332384430 300 10 Cantilever arms 38/40 2 light 120×40×6
332384440 400 7 Cantilever arms 38/40 2 light 120×40×6
332384450 500 7 Cantilever arms 38/40 2 light 120×40×6
332384460 600 1 Cantilever arms 38/40 2 light 120×40×6
332384471 - 700 1 Cantilever arms 38/40 2 light 120×40×6
332384475 750 1 Cantilever arms 38/40 2 light 120×40×6
332384480 800 1 Cantilever arms 38/40 2 light 120×40×6
332384490 900 1 Cantilever arms 38/40 2 light 120×40×6
332384495 950 1 Cantilever arms 38/40 2 light 120×40×6
